Beer Bottling Equipment
Jndwater beer bottling Equipment is used to fill beer into glass bottles. It can efficiently complete a series of operations from rinsing, filling to capping to ensure the hygiene and quality of beer.
Beer Bottling Equipment detailed description
Products Description
1. Product introduction
Jndwater beer bottling Equipment is used to fill beer into glass bottles. It can efficiently complete a series of operations from rinsing, filling to capping to ensure the hygiene and quality of beer.
2. Product features
High-precision filling
High degree of automation
Strong durability
Anti-drip design
CIP cleaning function
3. Product functions
Filling function
Automatic cleaning
Automatic detection
No filling if no bottle
Soft support mechanism
4. Technical specifications
| Model | JND 16-12-6G | JND 18-18-6G | JND 24-24-8G | JND 32-32-10G |
| Production Capacity(BPH)(500ml) | 3000 | 5000 | 8000 | 10000 |
| Applicable Bottle Type | (Bottle Diameter)Φ50-Φ100mm (Height) 150-320mm (Volume) 250-2000ml | |||
| Total Power (Kw) | 2.2 | 3 | 4 | 5.5 |
| Total Weight(Kg) | 3000 | 3800 | 5200 | 6500 |
| Dimension(L*W*H)(mm) | 2450*1830*2030 | 2830*2030*2030 | 3220*2300*2600 | 3450*2510*2710 |
5. How does the water bottling machine work?
Container preparation: Empty bottles or cans enter the filler through the conveyor system.
Cleaning: The container passes through the cleaning system to remove dust and impurities.
Filling: The filling valve is opened and beer is poured into the container under isobaric or negative pressure conditions.
Sealing: After filling, the container is sealed to prevent beer oxidation or leakage.
Output: The filled container is sent out and enters the next process (such as labeling, packaging).
6. Applications
Brewery: used for large-scale production of beer.
Beverage factory: suitable for filling carbonated drinks, juice and other liquid beverages.
Craft brewery: small filling machines are suitable for small batch production.
7. FAQ
How long is the service life of the equipment?
Under normal maintenance and use conditions, the service life of the equipment can generally reach more than 10 years.
