Seawater Desalination Machine
Jndwater seawater desalination machine employs advanced reverse osmosis (RO) membrane separation technology, specifically designed for treating highly saline seawater (TDS 30,000–45,000 mg/L), and can convert seawater into freshwater that meets drinking water standards
Seawater Desalination Machine detailed description
Products Description
1. Product introduction
Jndwater seawater desalination machine employs advanced reverse osmosis (RO) membrane separation technology, specifically designed for treating highly saline seawater (TDS 30,000–45,000 mg/L), and can convert seawater into freshwater that meets drinking water standards
2. Sea Water Desalination Product features
Efficient desalination: using multi-layer composite reverse osmosis membrane group, desalination rate ≥ 99.7%
Intelligent control: equipped with PLC real-time monitoring of water quality, pressure and energy consumption, supporting remote operation and maintenance and fault diagnosis.
Energy recovery optimization: multi-stage pretreatment (sand filtration, carbon filtration, precision filtration) combined with chemical cleaning system to extend the membrane life to more than 5 years.
Environmental adaptability: The main body is made of 316L stainless steel and titanium alloy
3. Water Desalination Machine Product functions
Pretreatment: Pre-treat seawater through multi-media filters and precision filters to reduce seawater turbidity.
Reverse osmosis treatment: Use a high-pressure pump to send seawater into the reverse osmosis membrane to remove salt and impurities in the seawater.
Energy recovery: Equipped with energy recovery devices to reduce energy consumption.
Water quality monitoring: Online water quality detection and control to ensure stable effluent water quality.
Self-protection: Equipped with high-pressure unloading and low-pressure shutdown protection functions to ensure safe operation of the equipment
4. Technical specifications
| JND-SW1 | 0.05 | 4~6.5 | 15 | 580×440×1600 |
| JND-SW2 | 0.1 | 4~6.5 | 11 | 580×440×1600 |
| JND-SW5 | 0.25 | 4~6.5 | 8 | 650×440×1600 |
| JND-SW10 | 0.5 | 4~6.5 | 7.8 | 800×600×1700 |
| JND-SW20 | 1 | 4~6.5 | 7.5 | 2500×700×1200 |
| JND-SW50 | 2.5 | 4~6.5 | 7 | 2500×1200×1700 |
| JND-SW100 | 5 | 4~6.5 | 6 | 3400×1500×1800 |
| JND-SW200 | 10 | 4~6.5 | 4 | 3400×2000×1800 |
| JND-SW5100 | 21 | 4~6.5 | 3.5 | 7500×2500×1800 |
5. How does the desalination work?
Pretreatment stage: Seawater is filtered through multi-media to remove suspended matter, colloids and microorganisms, and then the precision filter element is used to intercept particles ≥5 μm.
High-pressure boosting: The plunger pump pressurizes the pretreated water to 5.5-6.5 MPa, breaking the osmotic pressure balance of seawater.
Membrane separation: High-pressure seawater enters the RO membrane stack, water molecules pass through the membrane wall to form fresh water, and high-concentration brine is discharged after energy recovery.
6. Applications
Municipal water supply
Industrial applications
Ship and offshore platform
Emergency rescue
Ecological protection
7.FAQs
Q: Is the seawater desalination difficult to operate?
A: Desalination machine is easy to operate and maintain. As long as there is electricity and seawater, it can supply fresh water after startup.
