Double Side Labeling Machine – JND WATER

The Jndwater double-sided labeling machine is an automated equipment used to simultaneously label both sides of a container. Mainly used in industries such as food, beverage, daily chemical, pharmaceutical, electronics, etc., suitable for symmetrical or double-sided labeling of flat, square, oval, cylindrical, and irregular containers

Wide applicability, can simultaneously meet the single/double label labeling of cylindrical or conical products, with adjustable front and back label spacing, and optional positioning detection device can achieve circumferential positioning labeling;

Accurate labeling with high stability, using PLC+subdivision stepper motor to drive label feeding. Accurate label feeding with cam brake mechanism, uniform tension, ensuring label tension, reducing label breakage, and ensuring accurate label detection; The correction mechanism for guiding the tape can prevent the label from shifting left and right, ensuring the accuracy of the label and high overlap of the labels; The labeling mechanism adopts an integrated support rod to avoid displacement of the active labeling mechanism when the traditional labeling mechanism is pressed by the driven shaft. The rigidity is strengthened to ensure the accuracy of labeling. The adjustment of the passive labeling mechanism uses a guide sleeve instead of the traditional ink bearing, making the adjustment more precise and reducing the vibration of bottle squeezing during labeling, resulting in more accurate labeling;
Flexible application, bottle standing labeling, with automatic bottle separation function, can be produced independently or connected to assembly line production;
Powerful function, with six degrees of freedom adjustable in the x/y/z directions and tilt angle of the labeling area, providing all-round adjustment without blind spots. The tilt adjustment handwheel replaces the traditional machine that requires a hex wrench to adjust the tilt angle, greatly reducing the difficulty of operation; Color touch screen control, fully Chinese operation interface, convenient and intuitive, powerful data memory function, can store 50 sets of labeling parameters, switch between different product labels with one click, no need for repeated debugging, simple and fast; And it has complete fault prompts and assistance functions; Convenient production management with functions such as label counting and photoelectric tracking labels, making production management easier;
High stability, using imported first-line brands for measuring targets and object sensors, with high detection sensitivity, stable performance, and durability;
Safe and hygienic, in compliance with GMP excellent manufacturing standards
