Vegetable Oil Filling Machine
The Jndwater vegetable oil weighing filling machine is an automated equipment designed for vegetable oil filling. It can accurately control the filling volume to ensure the consistent weight of each barrel of vegetable oil. The equipment is widely used in the filling production of edible oil, vegetable oil, lubricating oil and other liquids to ensure product quality and production efficiency.
Vegetable Oil Filling Machine detailed description
Products Description
1. Product introduction
The Jndwater vegetable oil weighing filling machine is an automated equipment designed for vegetable oil filling. It can accurately control the filling volume to ensure the consistent weight of each barrel of vegetable oil. The equipment is widely used in the filling production of edible oil, vegetable oil, lubricating oil and other liquids to ensure product quality and production efficiency.
2.Vegetable Oil Filling Machine Product features
Adopt advanced weighing sensors and control systems
Automate the entire process from barrel feeding, filling to capping to improve production efficiency.
Applicable to barrels of various specifications and shapes, including common specifications such as 5L, 10L, 20L, etc.
Parts in contact with vegetable oil are made of food-grade stainless steel and meet hygiene standards
Equipped with an intuitive operating interface, easy to use and convenient to maintain.
Adopt energy-saving design to reduce production costs.
3. Product functions
PLC program control and intelligent sensors realize accurate quantitative and rapid filling of hand sanitizer.
Equipped with touch screen and remote monitoring system, real-time display of production data and equipment status
Built-in air filtration and ultraviolet sterilization system to ensure that the filling process remains sterile.
With automatic alarm and fault self-diagnosis function
4. Technical specifications
Filling speed 300-600 barrels/hour
Number of filling heads 2-4
Applicable barrel types 5L, 10L, 20L, etc.
Filling accuracy ±0.5%
Power supply 380V/50Hz
Power 5KW
Air source pressure 0.5-0.8MPa
Dimensions 2000×1500×2000mm
Weight 2500KG
5. How does the oil filling machine work?
Into the barrel: The empty barrel enters the filling machine through the conveyor belt.
Weighing: The equipment automatically weighs to ensure the accurate weight of each barrel.
Filling: The filling valve is opened, and the vegetable oil flows into the barrel under gravity or pressure. During the filling process, the accuracy of the filling amount is ensured by high-precision weighing sensors and control systems.
Capping: After filling, the automatic capping device tightens the barrel cover to ensure sealing.
Out of the barrel: The capped barrel enters the next process through the conveyor belt.
6. Applications
Food industry: vegetable oil filling machine for filling and production of edible oil, vegetable oil, olive oil, peanut oil, soybean oil and other liquid vegetable oils
Seasoning industry: filling of various seasoning oils, cooking oils, sauces and other liquid seasonings
Cosmetics industry: high viscosity vegetable oils, such as massage oils, skin care oils and other products.
Pharmaceutical industry: can be used for packaging of pharmaceutical oils
7.FAQs
Q: Does the vegetable oil filling machine support filling of different bottle types?
A: Yes, the equipment can be adjusted according to different bottle types, adapting to various bottle types and capacities from 250ml to 5000ml, and adapting to various packaging needs
